P90 Diaphragm Pump - Fluimac

Availability: 10
Other Variant:
PP PVDF+CF ALU( P 100 ) SS ( P 100 )
Share With
Order Now
-

TECHNICAL DATA



Fluid Connections3/4" BSP
Air Connection3/8" BSP
Max. Flow Rate100 lt/m
Max Air Pressure8 bar
Max Delivery Head80 m
Max Suction Lift Dry5 m
Max Suction Lift Wet9,8 m
Max Solid Passing4 m
Noise Level72 dB
Max Viscosity25.000cps
Displacement Per Stroke200cc

DIMENSION



ABCNET WIGHTTEMPERATURE
PP293 mm176 mm280 mm5,1 Kg- 4 °C|+65°C
PVDF293 mm176 mm280 mm6,6 Kg-20°C|+95°C
ALU265 mm178 mm245 mm5,6 Kg-20°C|+95°C
SS247 mm178 mm251 mm7,6 Kg-20°C|+95°C

COMPOSITION


MODELCASINGDIAPHRAGMBALLSSEATSGASKETCONNECTIONSATEXPORTS

P0090

P0100

P PP

KC PVDF+CF

S SS

A ALU

HT  HYTREL+PTFE

MT  SANTOPRENE+PTFE

H  HYTREL

M SANTOPRENE

D EPDM

N NBR

T PTFE

S SS

D EPDM

N NBR

P PP

K PVDF

S SS

Z PE-UHMWE

A ALU

D EPDM

V VITON

N NBR

T PTFE

1 BSP

2 FLANGED

5 NPT

- ZONE 2AB STANDARD
