P3 Diaphragm Pump - Fluimac

Availability: 10
Other Variant:
PP PVDF+CF POMc
Share With
Order Now
-

TECHNICAL DATA



Fluid Connections1/4" BSP
Air Connection4 mm
Max. Flow Rate4 lt/m
Max Air Pressure6 bar
Max Delivery Head60 m
Max Suction Lift Dry3 m
Max Suction Lift Wet9,8 m
Max Solid Passing2 m
Noise Level62 dB
Max Viscosity5.000cps
Displacement Per Stroke18cc

DIMENSION



ABCNET WIGHTTEMPERATURE
PP129 mm68 mm112 mm0.84 Kg+65°C
PVDF129 mm68 mm112 mm0.96 Kg+95°C
POMc129 mm68 mm112 mm0.84 Kg+80°C

COMPOSITION


MODELCASINGDIAPHRAGMBALLSSEATSGASKETCONNECTIONSATEXPORTS

P0007

P PP

KC PVDF+CF

O POMC

NT  NBR+PTFE

T PTFE

S SS

P PP

K PVDF

O POMc

D EPDM

V VITON

N NBR

T PTFE

1 BSP

5 NPT

- ZONE 2AB STANDARD
